IS200SRTDH2ABB | 印刷電路板 | 具有不同尺寸的電子元件
模型:IS200SRTDH2ABB
效率:大于90%。
尺寸:170mm x105mmx32mm。
重量:約120g。
工作溫度:-20℃~ +50℃。
存儲溫度:-40℃~ +70℃。
環境濕度:相對濕度5% ~ 95%(無凝露)
產品描述
IS200SRTDH2ABB是由通用電氣或通用電氣創建的印刷電路板或PCB，作為Mark VI家族的一部分。Mark VI是通用電氣Mark系列的最新版本。Mark系列中的Mark VI和其他系列旨在管理和自動化燃氣輪機和蒸汽輪機系統中的流程。它們被用于世界各地的許多不同行業。
IS200SRTDH2ABB是一種相對較小的印刷電路板，具有不同尺寸的電子元件。兩(2)個大端子位于IS200SRTDH2ABB的底邊，一個在另一個的上面。每個終端包含十八(18)個終端，總共有三十六(3)個終端。這些包含在終端內的銀色金屬終端從一(1)到三十六(36)編號，并帶有白色字母。一(1)個大連接器端口連接到IS200SRTDH2ABB的頂部邊框。該接口用于將附加組件或其他單板連接到IS200SRTDH2ABB上。IS200SRTDH2A的中心被一組二極管和電容器占據。二極管的形狀像一個黑色矩形。有24個二極管，分成兩(2)行水平排列，每行12個二極管。每個二極管旁邊是一(1)或兩(2)小矩形電容器。IS200SRTDH2ABB的左上角打印了該設備的完整IS200SRTDH2A部件名稱。GE符號印在電路板上，在這個零件號下面。
Model: IS200SRTDH2ABB
Efficiency: greater than 90%.
Size :170mm x105mmx32mm.
Weight: About 120g.
Operating temperature :-20°C to +50°C.
Storage temperature :-40°C to +70°C.
Ambient humidity :5% to 95% relative humidity (no condensation)
Product description
The IS200SRTDH2ABB is a printed circuit board or PCB created by General Electric or General Electric as part of the Mark VI family. The Mark VI is the latest version of the General Electric Mark series. The Mark VI and other series in the Mark series are designed to manage and automate processes in gas turbine and steam turbine systems. These are used in many different industries around the world.
The IS200SRTDH2ABB is a relatively small printed circuit board with electronic components of varying sizes. Two (2) large terminals are located on the bottom edge of the IS200SRTDH2ABB, one on top of the other. Each terminal contains eighteen (18) terminals for a total of thirty-six (3) terminals. These silver metal terminals contained within the terminal are numbered from one (1) to thirty-six (36) and bear white lettering. One (1) large connector port is connected to the top bezel of the IS200SRTDH2ABB. This connector port is used to connect additional components or other boards to the IS200SRTDH2ABB. The center of the IS200SRTDH2A is occupied by a collection of diodes and capacitors. The diode is shaped like a black rectangle. There are twenty-four diodes, divided into two (2) horizontal rows of twelve (12) diodes per row. Next to each diode are one (1) or two (2) small rectangular capacitors. The full IS200SRTDH2A part name for the device is printed in the upper left corner of the IS200SRTDH2ABB. The GE symbol is printed on the circuit board below this part number.
