IC693CPU321RR | 10 插槽底板 | 最多支持 320 個離散輸入
產(chǎn)品描述
GE Fanuc IC693CPU321 是一款 10 插槽底板，與電池附件套件 - IC693ACC315 兼容。此底板具有嵌入式 CPU。要將套件安裝到此底板中，用戶需要將附件板上的背板連接器與IC693CPU321的電源連接器對齊。它位于底板的背板上。將附件板推向底板，確保其完全就位非常重要。在運輸已安裝電池附件的底板時，分銷商必須注意包裝組件。需要使用扎帶將電路板固定到位。
IC693CPU321 CPU 底板最多支持 320 個離散輸入和 320 個離散輸出，或 64 個模擬輸入和 32 個模擬輸出。IC693CPU321 CPU 底板在電源上有 1 個內(nèi)置 RS-485 15 針 D 型母連接器端口，用于連接運行基于 GE Fanuc Windows 的 PLC 編程軟件的個人計算機、GE Fanuc 手持編程器和其他串行設備。它還支持其他通信選項，如串行 SNP、RTU、LAN-Genius、以太網(wǎng) SRTP、以太網(wǎng) Modbus TCP、Profibus-DP 和 DeviceNet 模塊。IC693CPU321底板支持使用基于 DOS 的 LogicMaster、基于 Windows 的 Versa-Pro 和 Proficy Logic Developer (Machine Edition) 軟件進行軟件配置。IC693CPU321 CPU 底板具有用于應用存儲的 12 KB 電池備份用戶邏輯存儲器，在 5 V DC 電壓下的最大背板電流消耗為 430 毫安。
Product description
The GE Fanuc IC693CPU321 is a 10-slot baseboard compatible with the battery accessory kit - IC693ACC315. This backboard has an embedded CPU. To install the kit into this baseboard, the user needs to align the backplane connector on the accessory board with the power connector of the IC693CPU321. It is located on the backplane of the base plate. It is important to push the attachment plate towards the base plate to ensure that it is fully in place. When shipping baseboards with battery accessories installed, the distributor must pay attention to the packaging components. Use cable ties to secure the circuit board in place.
The IC693CPU321 CPU backboard supports up to 320 discrete inputs and 320 discrete outputs, or 64 analog inputs and 32 analog outputs. The IC693CPU321 CPU backboard has a built-in RS-485 15-pin type D female connector port on the power supply for connecting personal computers running GE Fanuc Windows-based PLC programming software, GE Fanuc handheld programmers, and other serial devices. It also supports other communication options such as serial SNP, RTU, LAN-Genius, Ethernet SRTP, Ethernet Modbus TCP, Profibus-DP, and DeviceNet modules. The IC693CPU321 baseboard supports software configuration using DOs-based LogicMaster, Windows-based Versa-Pro, and Proficy Logic Developer (Machine Edition) software. The IC693CPU321 CPU backboard features 12 KB battery backup user logic memory for application storage, with a maximum backplane current consumption of 430 mah at 5 V DC.
