IC693CPU323RR | CPU 模塊 | 支持 SNP 從站和 SNP-X 從站協議的串行接口
技術規格
型號：IC693CPU323RR
處理器速度 ： 10兆赫
I/O 積分 ： 320
寄存器存儲器 ： 2KB字節
浮點數學： 不
16 位系統 是的
處理器： 80188
產品描述
GE FanucIC693CPU323RR 是一款 10 插槽基本 Turbo CPU。本機具有12 Kb的用戶程序存儲器。90-30 系列 PLC 系列包括控制器和 I/O 系統以及專用模塊。這些都是專門為用戶提供更通用和更廣泛的工業應用和過程控制系統而設計的。由于可用的模塊范圍很廣，因此很容易將自動化流程引入您的業務。該系列包括 14 個功能強大的 CPU 單元。IC693CPU323 是標準 CPU，最適合具有低 I/O 數量的入門級應用程序。由于 CPU 嵌入在背板中，因此所有 I/O 插槽都可供使用。運動控制和以太網等高級模塊可用于此 CPU。
=
該IC693CPU323RR的 CPU 被歸類為 turbo CPU，其典型掃描速率為每 1K 布爾邏輯 0.6 毫秒。它加載了 12KB 的用戶內存，對于版本 7 之前的版本，最大或 6KB。它支持多達 320 個離散 I/O 點;64 個模擬輸入字和 32 個模擬輸出字。該IC693CPU323配有 340 個單位的定時器和計數器，還支持移位寄存器指令。
用于IC693CPU323RR 的處理器是 80188，時鐘速度為 10 MHz。它還提供了支持 SNP 從站和 SNP-X 從站協議的串行接口。它還支持安裝可選通信功能，包括以太網、FIP、Profibus、GBC、GCM、GCM+ 選項模塊。
除了是不可擴展的硬件外，IC693CPU323RR 不支持覆蓋功能、電池備份時鐘和程序中斷。默認情況下，它使用電池備份的 RAM，但是，電池實際上由電源模塊托管。它還可以與可選的非易失性存儲器(如 EPROM 和 EEPROM)一起安裝。.
Technical specification
Model: IC693CPU323RR
Processor speed: 10 MHZ
I/O score: 320
Register memory: 2KB bytes
Floating point math: No
16-bit system Yes
Processor: 80188
Product description
The GE FanucIC693CPU323RR is a 10-slot basic Turbo CPU. The unit has 12 Kb of user program memory. The 90-30 series PLC series includes controllers and I/O systems as well as dedicated modules. These are specifically designed to provide users with more general and wider industrial applications and process control systems. Due to the wide range of modules available, it is easy to introduce automated processes into your business. The series includes 14 powerful CPU units. The IC693CPU323 is a standard CPU that is best suited for entry-level applications with low I/O counts. Since the CPU is embedded in the backplane, all I/O slots are available. Advanced modules such as motion control and Ethernet are available for this CPU.
The IC693CPU323RR CPU is classified as a turbo CPU with a typical scan rate of 0.6 ms per 1K Boolean logic. It loads 12KB of user memory, with a maximum or 6KB for versions prior to version 7. It supports up to 320 discrete I/O points; 64 analog input words and 32 analog output words. The IC693CPU323 is equipped with a 340 unit timer and counter, and also supports shift register instructions.
The processor for the IC693CPU323RR is 80188 with a clock speed of 10 MHz. It also provides a serial interface that supports the SNP slave and SNP-X slave protocols. It also supports the installation of optional communication features, including Ethernet, FIP, Profibus, GBC, GCM, GCM+ option modules.
In addition to being non-expandable hardware, the IC693CPU323RR does not support overwrite functionality, battery backup clock, and program interrupts. By default, it uses battery backup RAM, however, the battery is actually hosted by the PSU. It can also be installed with optional non-volatile memory such as EPROM and EEPROM.
