DS200TCQAG1B |5SHY5045L0020| 模擬 I/O 板|

DS200TCQAG1B 是通用電氣制造的 RST 模擬 I/O 板，是燃?xì)廨啓C(jī)控制系統中使用的 Mark V 系列的一部分。安裝在 I/O 內核 R1、R2 和 R3 上的終端板讀取的許多模擬信號都由模擬 IO 板 （TCQA） 進行縮放和調節。LVDT輸入、伺服閥輸出、熱電偶輸入、420 mA輸入和輸出、振動輸入、繼電器驅動器輸出、脈沖輸入、電壓輸入以及發電機和線路信號只是此列表中包含的信號中的一小部分。通過3PL連接器，一些信號被寫入STCA板。JE 連接器用于通過 TCQC 板發送和接收發生器和線路信號。TCQA 板可調節 420 mA 輸入信號，如壓縮機失速檢測信號和燃油流量壓力信號。

TCQA連接器如下

來自TCPS板的電源使用2PL分配到內核。

3PL - 數據總線是內核中 STCA、TCQA 和 TCQE 板之間的連接。為了傳輸?shù)紺OREBUS，有條件的信號在3PL上傳輸。

磁芯的熱電偶輸入和冷端補償分別由 JA 從 TBQA 板連接器 JAR/S/T 傳輸。

4–20 mA 的輸入和輸出由 JB 傳輸?shù)?TBQC 上的 JBR 端子板連接。

JD - 未用于 OR，但將跳閘信號從內核發送到內核中的 TCTG 板。

JE - 將脈沖信號、發生器和線路信號、繼電器驅動器輸出、伺服閥驅動器輸出等傳輸?shù)?TCQC 板或從 TCQC 板傳輸。承載電源監視器的輸入。

TBQC 端子板連接器 JFR 將 LVDT/LVDR 位置輸入發送到 JF。

JG 承載 +/- 10 V 直流輸入以及來自 TBQB 端子板連接 JGR 的振動輸入。

TCQA軟硬件配置

硬件：使用硬件跳線 J1 和 J2 選擇 mA 輸出電路。mA 輸出電流范圍（最大值為 20 mA）或最大值為 200 mA，使用 J5 和 J6 進行配置。對于卡測試，J7 中使用 RS232 端口。J8 打開振蕩器。有關此板的硬件跳線設置的詳細信息，請參閱附錄 A 和操作界面的硬件跳線面板。

軟件：熱電偶、脈沖速率、振動、LVDT 位置以及 420 mA 輸入和輸出 I/O 配置常數在操作界面上的 I/O 配置編輯器中輸入，如下所述。

脈率輸入電路

用于調整和調節脈沖速率輸入以通過 JE 連接器從 TCQC 板讀取的電路位于 TCQA 板上。這些信號從TTL（晶體管到晶體管邏輯）和磁拾音輸入輸入到QTBA和/或PTBA端子板中。高壓軸速度輸入被發送到“R1”磁芯。還有其他信號可以與R2和R3上的脈搏率輸入電路一起使用。

TCQA 4-20 mA 輸入電路

420 mA和01 mA輸入信號的電路由TCQA板提供。通過 JB 連接器，從 TBQC 端子板讀取信號。負載電阻兩端的壓降是由傳感器的電流降引起的，由 TCQA 板測量，并通過 3PL 連接器寫入 I/O 引擎。輸入信號的電流范圍使用TBQC端子板上的硬件跳線進行選擇。

TCQA 4-20 mA 輸出電路

通過JB連接器將420 mA輸出驅動到TBQC端子板的電路由TCQA板提供。通常，這些信號用于為控制設備供電。

The DS200TCQAG1B is an RST analog I/O board manufactured by General Electric and is part of the Mark V series used in gas turbine control systems. Many of the analog signals read by the end boards installed on the I/O cores R1, R2, and R3 are scaled and adjusted by the Analog IO Board (TCQA). LVDT inputs, servo valve outputs, thermocouple inputs, 420 mA inputs and outputs, vibration inputs, relay driver outputs, pulse inputs, voltage inputs, and generator and line signals are just a few of the signals included in this list. Through the 3PL connector, some signals are written to the STCA board. JE connectors are used to send and receive generator and line signals via the TCQC board. The TCQA board adjusts 420 mA input signals, such as compressor stall detection signals and fuel flow pressure signals.

The TCQA connectors are as follows

Power from the TCPS board is allocated to the kernel using 2PL.

The 3PL-data bus is the connection between the STCA, TCQA, and TCQE boards in the kernel. For transmission to COREBUS, conditional signals are transmitted on 3PL.

The thermocouple input and cold end compensation of the core are transmitted by JA from the TBQA board connector JAR/S/T, respectively.

The 4-20 mA input and output are connected by the JBR terminal board transmitted by the JB to the TBQC.

JD - is not used for OR, but sends trip signals from the kernel to the TCTG board in the kernel.

JE - Transmits pulse signals, generator and line signals, relay driver outputs, servo valve driver outputs, etc. to or from the TCQC board. Carries the input of the power monitor.

The TBQC terminal board connector JFR sends LVDT/LVDR position input to the JF.

The JG carries the +/ -10 V DC input and the vibration input from the TBQB terminal board connected to the JGR.

TCQA hardware and software configuration

Hardware: Select the mA output circuit using hardware jumpers J1 and J2. mA Output current range (maximum 20 mA) or maximum 200 mA, configured using J5 and J6. For card testing, the RS232 port is used in J7. J8 Turn on the oscillator. For more information about the hardware jumper Settings for this board, see Appendix A and the Hardware Jumper panel of the operating interface.

Software: Thermocouple, pulse rate, vibration, LVDT position, and 420 mA input and output I/O configuration constants are entered in the I/O configuration editor on the operating interface, as described below.

Pulse rate input circuit

The circuit used to adjust and adjust the pulse rate input to be read from the TCQC board via the JE connector is located on the TCQA board. These signals are fed from TTL (transistor to transistor logic) and magnetic pickup inputs into the QTBA and/or PTBA terminal boards. The high pressure shaft speed input is sent to the "R1" core. There are other signals that can be used with the pulse rate input circuitry on R2 and R3.

TCQA 4-20 mA input circuit

The circuits for the 420 mA and 01 mA input signals are provided by the TCQA board. The signal is read from the TBQC terminal board via the JB connector. The voltage drop at both ends of the load resistance is caused by the current drop of the sensor, measured by the TCQA board and written to the I/O engine via the 3PL connector. The current range of the input signal is selected using the hardware jumper on the TBQC terminal board.

TCQA 4-20 mA output circuit

The circuit to drive the 420 mA output to the TBQC terminal board via the JB connector is provided by the TCQA board. Typically, these signals are used to power control devices.
