SBRIO-9607 | 單板控制器 | 用于控制和處理時序相關的任務
型號：SBRIO-9607
類別：單板控制器
數字I/O，RMC，667 MHz雙核CPU，512MBDRAM，512MB存儲
Zynq-7020 FPGA CompactR10單板控制器
sbR10-9607是一款嵌入式控制器，在單塊印刷電路板(PCB)上集成了運行Nl Linux Real-Time的實時處理器、用戶可重配置FPGA和VO。包括-個RIO夾層 卡(RMC)連接器。這是一種高速高帶寬連接器直接訪問處理器和數字VO FPGA線。sbR10-9607可輕松嵌入需要靈活
性、可靠性和高性能的大批量OEM應用中。該控制器具有集成的千兆位以太網、CAN、串行和USB端口以及96條3.3V數字I0線。
SBRIO-9607 單板控制器通常包括以下幾個主要部分：
定時控制邏輯電路：用于控制和處理時序相關的任務。
指令寄存器(Register)：用于存儲CPU正在執行的指令。
譯碼器：將指令翻譯成具體的控制信號，以驅動其他部件執行相應的操作。
地址指針DPTR(Data Pointer Register)：用于存儲數據存儲器中數據的地址。
程序計數器PC(Program Counter)：由16位(8+8)寄存器構成的計數器，用于存儲下一條要執行的指令的地址。
堆棧指針SP(Stack Pointer)：用于指示數據在堆棧中的位置，以便進行函數調用和返回等操作。
Model: SBRIO-9607
Category: Board controller
Digital I/O, RMC, 667 MHz dual-core CPU, 512MBDRAM, 512MB storage
Zynq-7020 FPGA CompactR10 Board controller
The sbR10-9607 is an embedded controller that combines a Real-Time processor, user-reconfigurable FPGA, and VO running Nl Linux Real-Time on a single printed circuit board (PCB). Includes - a RIO Sandwich card (RMC) connector. It is a high-speed high-bandwidth connector with direct access to processor and digital VO FPGA lines. The sbR10-9607 can be easily embedded as flexible as required
Performance, reliability and high performance in high volume OEM applications. The controller features integrated gigabit Ethernet, CAN, serial and USB ports and 96 3.3V digital I0 cables.
The SBRIO-9607 single board controller usually includes the following main parts:
Timing control logic circuit: Used to control and process timing related tasks.
Instruction Register (Register) : Used to store the instructions that the CPU is executing.
Decoder: Translates instructions into specific control signals to drive other components to perform corresponding operations.
Data Pointer Register (DPTR) : An address used to store data in the data store.
PC (Program Counter) : A counter consisting of 16 bit (8+8) registers that store the address of the next instruction to be executed.
Stack Pointer SP (Stack Pointer) : Used to indicate the position of data in the stack for operations such as function calls and returns.
