>>>>>型號:5466-316 四個速度輸入調速器 增加單獨的雙通道
【功能描述】
MicroNet 5466-253和5466-316 HDCombo模塊于1997年首次推出，用于蒸汽控制市場。該模塊包括8個模擬輸入，4個模擬輸入
輸出，四個速度輸入，和兩個比例執行器輸出。-253版本具有TMR和5009系統控制閥與比例執行器的I/O的理想組合。
Woodward最新的速度/模擬組合模塊(5466-1115)缺乏老式HDCombo模塊的板載比例執行器功能，需要增加單獨的雙通道
致動器模塊。這消耗了主TMR機箱中寶貴的I/O空間。自2016年以來，Woodward一直提供HDCombo模塊，主要用于備件和系統升級，并推動蒸汽和壓縮機客戶使用5466-1115以及補充的2CH執行器控制模塊。伍德沃德的5009標準汽輪機控制也改為利用較新的組合模塊。
從2020年底開始，標準的5009XT汽輪機控制將改為使用5466-253 HDCombo模塊代替5466-1115 Combo模塊。自定義編程
微網TMR系統可以使用任何一種配置。伍德沃德建議使用5466-253對TMR系統，如果渦輪機使用比例致動器，并使用5466-1115，如果渦輪機使用集成致動器或單獨的伺服控制器，如SPC。5466-316可用于需要該模塊提供的特定I/O和FTM的改造系統。
輸入/輸出通道： 5466-316 模塊通常具有多個輸入和輸出通道，用于連接外部傳感器、執行器和設備。
數字和模擬信號： 這種類型的模塊通常支持?jǐn)?shù)字輸入和輸出，以及模擬輸入和輸出，以滿足不同類型的信號和傳感器需求。
電壓/電流范圍： 這些模塊通常支持不同的電壓和電流范圍，以適應不同類型的信號和負載。
通信接口： 5466-316 模塊通常具有標準的通信接口，以便與PLC或其他控制系統進行數據交換和通信。
可編程性： 用戶通?？梢耘渲煤途幊踢@些模塊，以生成特定的輸入/輸出邏輯和控制。
狀態監測： 這些模塊通常具有狀態監測功能，允許實時監測輸入和輸出通道的狀態。
保護功能： 輸入模塊通常具有保護功能，例如過壓保護、過流保護，以確保系統的安全性和可靠性。
>>>>>型號:5466-316 四個速度輸入調速器 增加單獨的雙通道
【英文介紹】
The MicroNet 5466-253 and 5466-316 HDCombo modules were first introduced in 1997 for the steam control market. The module includes 8 analog inputs and 4 analog inputs
Outputs, four speed inputs, and two proportional actuator outputs. The -253 version has the ideal combination of TMR and 5009 system control valves with proportional actuator I/O.
Woodward's latest speed/analog combination module (5466-1115) lacks the on-board proportional actuator feature of the older HDCombo module, requiring the addition of a separate dual channel
Actuator module. This eats up valuable I/O space in the main TMR chassis. Woodward has been offering the HDCombo module since 2016, primarily for spare parts and system upgrades, and to drive steam and compressor customers to the 5466-1115 as well as the complementary 2CH actuator control module. Woodward's 5009 standard turbine control was also changed to utilize a newer combination module.
From the end of 2020, the standard 5009XT turbine control will be replaced by 5466-253 HDCombo modules instead of 5466-1115 Combo modules. Custom programming
Microgrid TMR systems can be used in either configuration. Woodward recommends using 5466-253 for TMR systems if the turbine uses proportional actuators, and using 5466-1115 if the turbine uses integrated actuators or a separate servo controller, such as an SPC. The 5466-316 can be used in retrofit systems that require the specific I/O and FTM provided by this module.
Input/output channels: 5466-316 modules typically have multiple input and output channels for connecting external sensors, actuators, and devices.
Digital and analog signals: This type of module typically supports digital inputs and outputs, as well as analog inputs and outputs, to meet different types of signal and sensor needs.
Voltage/current range: These modules typically support different voltage and current ranges to accommodate different types of signals and loads.
Communication interface: The 5466-316 module usually has a standard communication interface for data exchange and communication with a PLC or other control system.
Programmability: Users can typically configure and program these modules to generate specific input/output logic and controls.
Condition monitoring: These modules often have condition monitoring capabilities that allow real-time monitoring of the status of input and output channels.
Protection function: The input module usually has protection functions, such as overvoltage protection and overcurrent protection, to ensure the safety and reliability of the system.
